Application and Features:
The fog penetrating laser detector is a new generation high-power laser detector developed by our factory. It is specifically designed for harsh work sites in the metallurgical industry, using high-power semiconductor lasers with a peak power of 60W
As the emission source, the infrared laser tube has extremely strong penetration ability and a very long operating distance.
The T30 fog penetrating laser detector has the following characteristics:
1. Can work in harsh environments such as high temperature, humidity, water mist, dust, etc.
2. Can work continuously and reliably for a long time.
3. This detector integrates power supply, controller, and output, and is easy to install.
Technical parameters:
1. Detection area (distance between transmission and reception): ≤ 100m；
2. Emission light source: Infrared semiconductor laser with a wavelength of 905nm;
3. Peak power of transmission output: 60W;
4. Laser safety level: CLASS IIIb；
5. Output:
(1) Transmitter:
A set of normally open and normally closed relay signal outputs: When the transmitter is working normally, the relay is disconnected; When the transmitter is working abnormally, the relay closes. Maximum load capacity DC30V/10A, 250VAC/10A
(2) Receiver:
A set of push-pull level output: maximum load capacity of 100mA, with overload protection and short circuit protection. The output polarity can be switched through an internal on-off dip switch, with a response time of 10ms.
A set of relay outputs: response time of 20ms, maximum load capacity of DC30V/10A, 250VAC/10A
Optional energy receiving alarm output: MOS relay output, maximum load capacity DC60V/2.5A. When the received energy is ≤ 20, the MOS relay closes
6. Environmental temperature range- 25℃~70℃
7. Power consumption: transmitter 5W; Receiver no-load power consumption 5W, full load power consumption 15W
8. Anti environmental light drying: 10000LUX, suitable for detecting objects below 1200 ℃.
