Description
Applications and characteristics:
The laser stadiometer is specifically designed for distance measurement of harsh field artifacts in the work industry. The main characteristics are as follows:
- maintain high measurement precision and reliability under harsh industrial use environments;
- measurement range 10 m, 30 m, 100 m (the company has additional multiple different measurements for different occasions of use);
- use of a visible red laser beam that is easy to target the subject;
- rich output interfaces, multiple switching volumes, an-alog volumes, and digital communication interfaces optional for access to various control systems;
- convenient key operation sets various parameters;
- flexible and scalable connecting cable to facilitate on-site connections;
Technical parameters:
Measurement range: 0.2… 100 m (refer to white paper 500 x 500 mm, 90% reflection);
The measurement range is related to the target reflectivity, stray light, and environmental conditions;
The use of special reflectors can reach up to 150m;
Measurement accuracy: ± 3mm, with an accuracy of ± 2mm within a measurement range of 30 meters
Application scope: 0.2…150 m；
Laser wavelength: 650nm for red light;
Laser divergence angle: 0.6mrad;
Laser protection level: Class 2
Supply voltage: DC24V DC ± 20%, power<=10w< p=””>
Digital output: RS485, RS232, Profibus DP optional;
Analog output: 4-20mA, 0-24mA, 0-20mA, 4-24mA, 0-10V, 0-5V optional;
The measurement range corresponding to the analog quantity can be set through the menu;
Relay output: AC250V，10A； DC30V，10A；
Response time less than 300ms;
Level output: high>=22V, low<=2V, maximum load capacity of 100ma, with short-circuit protection< p=””>
The high and low output of actions can be switched through menu settings;
Response time less than 100ms;
Working temperature: -10 ℃~50 ℃, water-cooled and air-cooled:- 10℃～110℃；
Protection level: IP65；
